5025-1480 (148cm profile)
Shutter Fence with Laser-Cut
Material: 60x60x1.5mm Galvanised Profile
Height: 148cm
Number of Panels to be Used: 1+1+14 (1 laser-cut top panel + 1 vertical laser-cut side panel + 14 shutter panels)
- The profiles used in shutter fence systems are 60x60x1.5mm galvanised profiles.
- Each profile is sold as a set together with its self-welded 120x120x6mm flange and plastic lid.
- For this product with a height of 148 cm, 1 horizontal laser-cut top panel + 1 vertical laser-cut side panel + 14 shutter panels (5101-2000) must be used.
Horizontal Laser-Cut Top Panel Alternatives:
For each panel at 148 cm height, 1 of the following models should be selected.
- 5110-2000
- 5111-2000
- 5112-2000
Laser-Cut Top Panels are manufactured from 1.5mm thick galvanised sheet metal.
Vertical Laser-Cut Side Panel Alternatives:
For each panel at 148 cm height, 1 of the following models should be selected.
- 5120-1450
- 5121-1450
- 5122-1450
Laser-Cut Top Panels are manufactured from 1.5mm thick galvanised sheet metal.
- Shutter Panel size alternatives:
For each panel at 148 cm height, 14 units of the following model should be used.
- 5101-2000
- The panels fit 20mm into the profiles.
- Shutter panels are manufactured from 1mm galvanised sheet metal.
- The product is sold either painted or unpainted, as preferred.
Kirimci Metal, Louvre Fence Systems
Louvre Fence Systems: Security, Aesthetics and Durability Combined
Kirimci Metal Louvre Fence Systems offer innovative fencing solutions that combine security with aesthetics in modern structures. Designed with advanced manufacturing technologies, these systems are preferred for both residential and industrial applications thanks to their durable structure, long-lasting materials and elegant appearance.
Modern Design – Maximum Security
Unlike classic fence models, louvre fence systems consist of horizontal metal slats. This structure limits visibility from outside, providing privacy, while also offering high protection against external factors. Kirimci Metal guarantees long-lasting resistance to rust and colour fading through galvanised steel and electrostatic powder coating applications.
Areas of Use
- Residential complexes and villas:Offers an aesthetic appearance together with security.
- Industrial facilities:Ideal for perimeter protection and security thanks to its robust structure.
- Public buildings and schools:A long-lasting solution in terms of durability and stylish appearance.
- Gardens and private properties:Provides an elegant boundary solution compatible with modern architecture.
Advantages
- Long-lasting metal construction
- Variety of colours and models
- Easy installation and maintenance
- High security standard
- Louvre structure providing privacy
A Perfect Harmony of Aesthetics and Function
Kirimci Metal Louvre Fence Systems stand out not only for their security but also for their design, which adds value to the structure they are part of. Their horizontal slat structure is in perfect harmony with the lines of modern architecture. As a result, they are used as a decorative element in both residential and commercial areas.
Related products
5015-1000 (100cm profile)
Louvre Fence
- Material: 60x60x1.5mm Galvanised Profile
- Height: 100cm
- Number of Panels Required: 11
- The profiles used in louvre fence systems are 60x60x1.5mm galvanised profiles.
- Each profile is sold as a set together with its self-welded 120x120x4mm flange and plastic lid.
- 11 panels are required for this product with a height of 100 cm. Panel size alternatives:
- 100cm (Code: 5101-1000),
- 120cm (Code: 5101-1200),
- 150cm (Code: 5101-1500),
- 200cm (Code: 5101-2000).
- The panels fit 20mm into the profiles.
- The panels are manufactured from 1mm galvanised sheet metal.
- The product is available painted or unpainted, as preferred.
5015-2000 (200cm profile)
Louvre Fence
- Material: 60x60x1.5mm Galvanised Profile
- Height: 200cm
- Number of Panels Required: 22
- The profiles used in louvre fence systems are 60x60x1.5mm galvanised profiles.
- Each profile is sold as a set together with its self-welded 120x120x6mm flange and plastic lid.
- 22 panels are required for this product with a height of 200 cm. Panel size alternatives:
- 100cm (Code: 5101-1000),
- 120cm (Code: 5101-1200),
- 150cm (Code: 5101-1500),
- 200cm (Code: 5101-2000).
- The panels fit 20mm into the profiles.
- The panels are manufactured from 1mm galvanised sheet metal.
- The product is available painted or unpainted, as preferred.
5015-400 (40cm profile)
Louvre Fence
Material: 60x60x1.5mm Galvanised Profile
Height: 40cm
Number of Panels Required: 4
The profiles used in louvre fence systems are 60x60x1.5mm galvanised profiles.
Each profile is sold as a set together with its welded-on 120x120x4mm flange and plastic lid.
For this 40 cm high product, 4 panels are required. Panel size alternatives:
- 100cm (Code: 5101-1000),
- 120cm (Code: 5101-1200),
- 150cm (Code: 5101-1500),
- 200cm (Code: 5101-2000).
The panels fit 20mm into the profiles.
The panels are manufactured from 1mm galvanised sheet.
The product is sold painted or unpainted upon request
5015-500 (50cm profile)
Nemrut (Shutter Fence)
- Material: 60x60x1.5mm Galvanised Profile
- Height: 50cm
- Number of Panels Required: 5
- The profiles used in shutter fence systems are 60x60x1.5mm galvanised profiles.
- Each profile is sold as a set together with its self-welded 120x120x4mm flange and plastic lid.
- 5 panels are required for this product with a height of 50 cm. Panel size alternatives:
- 100cm (Code: 5101-1000),
- 120cm (Code: 5101-1200),
- 150cm (Code: 5101-1500),
- 200cm (Code: 5101-2000).
- The panels fit 20mm into the profiles.
- The panels are manufactured from 1mm galvanised sheet metal.
- The product is sold either painted or unpainted, as preferred.
5015-750 (75cm profile)
Louvre Fence
- Material: 60x60x1.5mm Galvanised Profile
- Height: 75cm
- Number of Panels Required: 8
- The profiles used in louvre fence systems are 60x60x1.5mm galvanised profiles.
- Each profile is sold as a set together with its self-welded 120x120x4mm flange and plastic lid.
- 8 panels are required for this product with a height of 75 cm. Panel size alternatives:
- 100cm (Code: 5101-1000),
- 120cm (Code: 5101-1200),
- 150cm (Code: 5101-1500),
- 200cm (Code: 5101-2000).
- The panels fit 20mm into the profiles.
- The panels are manufactured from 1mm galvanised sheet metal.
- The product is available painted or unpainted, as preferred.
5015-850 (85cm profile)
Nemrut (Shutter Fence)
- Material: 60x60x1.5mm Galvanised Profile
- Height: 85cm
- Number of Panels Required: 9
- The profiles used in shutter fence systems are 60x60x1.5mm galvanised profiles.
- Each profile is sold as a set together with its self-welded 120x120x4mm flange and plastic lid.
- 9 panels are required for this product with a height of 85 cm. Panel size alternatives:
- 100cm (Code: 5101-1000),
- 120cm (Code: 5101-1200),
- 150cm (Code: 5101-1500),
- 200cm (Code: 5101-2000).
- The panels fit 20mm into the profiles.
- The panels are manufactured from 1mm galvanised sheet metal.
- The product is available painted or unpainted on request.
5030-700 (70cm profile)
Ilgaz (Horizontal Slat Modern Fence)
Material:60x60x1.5mm Galvanised Profile
Height:70cm
Number of Panels Required:7 (Code: 5130)
- The profiles used in louvre fence systems are 60x60x1.5mm galvanised profiles.
- Each profile is sold as a set together with its self-welded 120x120x4mm flange and plastic lid.
- For this product with a height of 70 cm, 7 panels (Code: 5130) are required.
Panel size alternatives:
- 100cm (Code: 5130-1000),
- 120cm (Code: 5130-1200),
- 150cm (Code: 5130-1500),
- 200cm (Code: 5130-2000).
- The panels fit 20mm into the profiles.
- The panels are manufactured from 1mm galvanised sheet metal.
- The product is sold either painted or unpainted, as preferred.
5040-900 (90cm profile)
Laser Cut Panel Profile
Material: 60x60x1,5mm Galvanised Profile
Height:90cm
- The profiles used in Laser Cut Panel fence systems are 60x60x1.5mm Galvanised profiles.
- Each profile is sold as a set together with its self-welded 120x120x4mm flange and plastic lid.
- In our IDA model, the panels have their own handrail and require no welding.
- For this product with a height of 90 cm, one of the following panels can be selected:
- 5150-820-1346
- 5150-820-1762
- 5150-820-1252
- 5150-820-1160
- Panels fit 25mm into the profiles.
- Panels are manufactured in 2mm Galvanised.
- The product is sold optionally painted or unpainted.
